| Engine
Specification |
| PETROL 280 |
| Type |
Single Cylinder, 4 stroke, |
|
Petrol Engine, OHC |
| Bore / Stroke |
74 mm / 64 mm |
| Displacements |
275 cc |
| Compression Ratio |
8.1 |
| Maximum Power |
9 H.P. @4400 RPM |
| Maximum Torque |
19 NM @ 2800 RPM |
| Oil Filter |
Spin On |
| Oil Quantity |
1.7 Ltr. |
| Air Cleaner |
Dry Type |
| Engine Weight |
30.5 kg. |
| Cooling System |
Forced Air Cooled |
| Fuel Consumption |
22+/-2 km/ltr. |
| DIESEL- 360 |
| Type |
Single Cylinder, 4 stroke, |
|
Diesel Engine |
| Bore / Stroke |
86mm / 68mm |
| Displacements |
395cc |
| Compression Ratio |
18.1 |
| Maximum Power |
7.5 HP. @ 3600 RPM |
| Maximum Torque |
17 Nm @ 2200 RPM |
| Oil Filter |
Spin On |
| Oil Quantity |
1.3 Ltr. |
| Air Cleaner |
Dry Type |
| Engine Weight |
45 kg |
| Cooling System |
Air Cooled |
| Fuel Consumption |
36 + /-2 km/ltr. |
| Engine
Petrol 340 |
| Type |
Four –stroke,
Single Cylinder, Petrol Engine, OHC |
| Bore/stroke,
mm |
82mm/64mm |
| Number of
cylinders |
One |
| Displacement |
338 cc |
| Compression
ratio |
8.1 |
| Air cleaner |
Dry type |
| Oil filter |
Spin On |
| Fuel filter |
Paper
element type |
| Capacity of
cooling system |
Forced Air
cooled |
| Oil sump
capacity |
1.5 Litre |
| Weight of
engine |
30kg. |
| Clutch |
| Type |
Multi-plate
wet type |
| Transmission |
| Type |
Constant
Mesh, Mechanical Selective |
| No. Of gears |
4 forward +
1 reverse |
| Gear ratios |
- 5:1
|
|
|
|
|
|
|
|
Reverse
5.94:1 |
| Front axle |
Bolted axle
on Leading links |
| Rear axle |
Fully
Floating axle shaft |
| Ratio |
1.142:1(Primary) |
|
4.125:1(Final) |
| Steering |
Handle bar |
| Chassis |
|
| Long member
size, mm |
Rectangular
Closed Section |
| Number of
cross members |
Round Tube |
| Suspension |
| Front |
Trailing
Link with Hydraulic Shock Absorber |
| Rear |
2 Nos. Semi
Elliptical Leaf Spring with Hydraulic Shock Absorber. |
| Brakes |
| Type |
Antidive,
all Three Wheels-Hydraulic Shok Adjusting Brakes With TMC |
| Front |
Drum brake |
| Rear |
Drum brake |
| Parking |
Mechanical
on Real wheel |
| Wheels &
Tyres |
4.5-10-8pr |
| Electrical System |
| System
voltage |
12 V |
| Battery |
12 V-52 Ah,
Multi plate Lead Acid Motorized, Single Glade |
| Alternator
(max. output) |
13.5V 35A at
3600rpm |
| Wiper |
Motorized,
Single blade |
| Fuel Tank |
| Capacity |
1.5 Litres |
| Fuel
Consumption |
22+_2km/ltr. |
| Water Tank Details |
| Length |
1294 mm |
| Width |
1240 mm |
| Height |
562 mm |
| Capacity |
500 litres |
| Overall
Dimensions |
|
| Length |
2692 |
| Height |
1829 |
| Width |
1296 |
|
|
