| Specification |
| Engine |
|
| Type |
2 Stroke, Single Cylinder |
| Bore and Stroke |
46 x 42 |
| Displacement |
69.9 cc |
| Maximum Power |
2.61 Kw (3.5 bhp) @ 5000 rpm |
| Torque (NM) |
5.0 @ 3750 rpm |
| Dimensions |
|
| Wheelbase (mm) |
1222 |
| Dry Unladen Weight (kg) |
75 |
| Gross Vehicle Weight |
205 |
| Brake drum front (mm) |
80 |
| Brake drum rear (mm) |
110 |
| Tyre size FR & R |
2.5 x 16 |
| Fuel tank capacity (Ltrs) |
4 (incl 1 litre reserve) |
| Electrical |
|
| Ignition system |
Fly wheel magneto 12V, 50W Electronic ignition |
| Head lamp |
12V-35/35W |
| Tail Lamp |
12V-5 W |
| Brake Lamp |
12V-10 W |
| Speedo Lamp |
12V-3.4 W |
| Horn |
12V-AC Type |
| Indicator Lamp |
12V- 5W |
| Suspension |
|
| Front |
Oil filled telescopic Spring assisted shocks |
| Rear |
Adjustable hydraulic spring arm shocks |
| Drive |
|
| Clutch |
Centrifugal wet type |
| Primary Drive |
Single speed gear box |
| Secondary Drive |
Roller chain drive |
| Colours Available |
Red, Blue, Green, Black |
 |
