| Specifications |
| Engine / Transmission |
|
| Engine |
4-Stroke OHC, Single Cylinder, Air Cooled |
| Bore x Stroke |
52.4 x 57.8 mm |
| Displacement |
124.7 cc |
| Compression Ratio |
9.1: 1 |
| Max Power |
6.72 Kw (9 BHP) @ 7000 rpm |
| Torque |
10.35 Nm @ 4000 rpm |
| Max Speed |
90 Kmph |
| Clutch |
4 - Speed Constant Mesh |
| Final Drive |
Roller Chain |
| Electricals |
|
| Ignition |
Digital - CDI Ignition (AMI) |
| Advanced Micro Processor Ignition system |
|
| Head Light |
12V - 35W Multi Reflector Halogen Bulb - AC Type |
| Starting |
Kick StartSelf Start (Optional) |
| Tyres |
|
| Front |
2.75 X 18 - 4 PR / 42P |
| Rear |
2.75 X 18 - 6 PR / 48P |
| Brakes |
|
| Front Drum Type |
Internal Expanding Type - 130 mm Dia |
| Front Disc Type |
Hydraulic Disc Type - 215 mm Dia (Optional |
| Rear |
Internal Expanding Type - 130 mm Dia |
| Suspension |
|
| Front |
Telescopic Hydraulic Fork |
| Rear |
Swing Arm with Hydraulic Shock Absorbers |
| Dimensions |
|
| Dimensions (LXWXH) |
1995 X 735 X 1095 mm |
| Wheel Base |
1265 mm |
| Ground Clearance |
150 mm |
| Kerb Weight |
117 Kg (Kick Version)
121 Kg (Self Version) |
| Frame |
Tubular Double Cradle |
| Fuel Tank Capacity |
12 Ltrs. (Min) |
| Colours Available |
Black, Silver, Red, Blue, Maroon |
| |
|
